T90
Lightweight Acoustic Ceiling Damper System
The T90 Lightweight Acoustic Ceiling Damper System delivers high sound insulation within a shallow 90–120 mm build-up, making it ideal for renovations and rooms with limited headroom. Rubber isolation clips on the metal-stud cassette-keel frame decouple the ceiling from the slab, while built-in shock dampers and SG-DM452 Vibration Damping Tape break residual sound bridges.
A 50 mm mineral / synthetic wool layer absorbs cavity resonance, and the composite insulation board plus plasterboard finish add the mass needed to reach STC 44 / Rw 44 dB at a fraction of the depth of a spring-hung system.
Exploded Mounting Structure
10 layers · top to bottom
Layer Build-up
- 1
Concrete Slab
- 2
Min. 80 kg/m³ Mineral / Synthetic Wool
600 × 1200 × 50 mm
- 3
M8 × 80 Expansion Bolt
- 4
Main Cassette Keel 37MB
- 5
Edge Cassette Keel 20EB
- 6
Sub Cassette Keel 50SB
- 7
SG-DM452 Vibration Damping Tape
45 × 6000 × 2 mm
- 8
Composite Sound Insulation Board
1220 × 1220 × 17–18 mm
- 9
Plaster Board
- 10
AcousPanel or Other Finishes
Layer Specifications
| Layer | Product | Specification | Application |
|---|---|---|---|
| Damper | Built-in Shock Damper | 20 × 20 × 10 mm | Break sound bridges |
| Absorption | Mineral Wool / Synthetic Wool | 600 × 1200 × 50 mm | Uses sound absorption to enhance insulation |
| Structure | Cassette Keel | Main: 37 mm | Sub: 50 mm | Edge: 20 mm | Secure fit with preserved acoustic decoupling |
| Damper | Vibration Damping Tape | 45 × 6000 × 2 mm | Minimized rigid connections |
| Insulation | Composite Sound Insulation Board | 1220 × 1220 × 17–18 mm | Greatly improves sound insulation performance |
System Description
Panel 1
1 × 100 mm Concrete
Frame
Rubber isolation clip on metal stud (37 mm × 26 mm), spacing 600 mm, cavity width 150 mm + 50 mm Mineral Wool (80 kg/m³)
Panel 2
1 × 8 mm Fibre Cement + 1 × 1.3 mm Rubber + 1 × 6 mm Plasterboard
Details
Panel size 2.4 m × 2.4 m · Partition surface mass 24.5 kg/m² · Mass-air-mass resonant frequency 146 Hz
Acoustic Performance
Sound Insulation Prediction
All STC, OITC and acoustic performance figures are estimated / simulated values (INSUL Sound Insulation Prediction v9.0.22, © Marshall Day Acoustics 2017) intended solely as design references — not guaranteed field performance. Final results depend on site conditions, construction details and installation quality, beyond the control of INSUL.
