Q140
Dual-Cavity Acoustic Wall System
The Q140 Dual-Cavity Acoustic Wall System is a free-standing acoustic partition for situations where there is no solid base wall to line. Deep Main 112MS and Sub 114SS cassette keels frame a wide dual cavity around a central partition board, giving two independent air gaps that break the airborne transmission path.
Filled with mineral / synthetic wool and finished with composite insulation board and plasterboard, the Q140 delivers STC 57 / Rw 57 dB as a complete stand-alone wall - suitable for new room divisions and back-of-house separation.
Exploded Mounting Structure
9 layers · top to bottom
Layer Build-up
- 1
With/Without Concrete Wall
- 2
Min. 80 kg/m³ Mineral / Synthetic Wool
600 × 1200 × 50 mm
- 3
Partition Board
- 4
Main Cassette Keel 112MS
- 5
Sub Cassette Keel 114SS
- 6
SG-DM452 Vibration Damping Tape
45 × 6000 × 2 mm
- 7
Composite Sound Insulation Board
1200 × 1200 × 16–18 mm
- 8
Plaster Board (by others)
- 9
AcousPanel or Other Finishes
Layer Specifications
| Layer | Product | Specification | Application |
|---|---|---|---|
| Absorption | Mineral Wool / Synthetic Wool | 600 × 1200 × 50 mm | Uses sound absorption to enhance insulation |
| Structure | Cassette Keel | Main: 112 mm | Sub: 114 mm | Secure fit with preserved acoustic decoupling |
| Damper | Vibration Damping Tape | 45 × 6000 × 2 mm | Minimized rigid connections |
| Insulation | Composite Sound Insulation Board | 1200 × 1200 × 16–18 mm | Greatly improves sound insulation performance |
System Description
Panel 1
1 × 6 mm Fibre Cement + 1 × 1 mm Rubber + 1 × 6 mm Fibre Cement
Frame 1
0.55 mm steel stud (50 × 38 mm), spacing 600 mm, cavity width 50 mm + 50 mm Rockwool (80 kg/m³)
Panel 2
1 × 10 mm Plasterboard
Frame 2
0.55 mm steel stud (50 × 38 mm), spacing 600 mm, cavity width 50 mm + 50 mm Rockwool (80 kg/m³)
Panel 3
1 × 6 mm Fibre Cement + 1 × 1 mm Rubber + 1 × 6 mm Fibre Cement
Details
Panel size 2.4 m × 2.4 m · Partition surface mass 54.4 kg/m² · Mass-air-mass resonant frequency 134 Hz
Acoustic Performance
Sound Insulation Prediction
All STC, OITC and acoustic performance figures are estimated / simulated values (INSUL Sound Insulation Prediction v9.0.22, © Marshall Day Acoustics 2017) intended solely as design references - not guaranteed field performance. Final results depend on site conditions, construction details and installation quality, beyond the control of INSUL.
